• Extends 1080p resolution up to 164ft/50m
• Supports ARC function
• Supports HDMI loop out function at Transmitter side
• Supports High Definition resolutions up to 1080P@60Hz
• Supports Bi-directional wideband IR control from source to display or from display to source
• Up to 16 different EDID configurations to meet most of use cases (including select local or remote display's EDID)
• Compact design for an easy and flexible installation
HDMI Compliance HDMI 1.4b
HDCP Compliance HDCP 1.4
Video Bandwidth 4.95 Gbps
Video Resolutions up to 1080P@60Hz
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 10-bit, 12-bit
Audio Formats PCM 2CH, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital+
ESD Protection Human body model - ±8kV (air-gap discharge) & ±4kV (contact discharge)
Inputs
TX:
1x HDMI Type A [19-pin female]
1x 3.5mm Stereo Mini-jack [Infrared Receiver]
RX:
1x RJ45 [HDMI & Propriety Data]
1x 3.5mm Stereo Mini-jack [Infrared Receiver]
TX:
1x HDMI Type A [19-pin female]
1x RJ45 [HDMI & Propriety Data]
1x 3.5mm Stereo Mini-jack [Infrared Emitter]
RX:
1x HDMI Type A [19-pin female]
1x Toslink Out [S/PDIF]
1x 3.5mm Stereo Mini-jack [Infrared Emitter]
Housing Metal Enclosure
Dimensions TX/RX: 100mm [W] x 65mm [D] x 25.6mm [H]
Net Weight TX: 178g RX: 176g
Power Supply Input: AC100 - 240V 50/60Hz
Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)
Power Consumption (Max) TX:3W RX: 2.2W
Operation Temperature 32 - 104°F / 0 - 40°C
Storage temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20 - 90% RH (no condensation)
