HDCP2.2/HDCP1.4 and DVI 1.0 compliant.
-
Supports HDMI resolution the maximum up to 4K2K@50/60Hz (4:2:0).
-
Supports digital and analog audio extract output from output A or output B.
-
EDID can be selected AUTO, COPY and STD mode via
HDCP Compliance HDCP 2.2 and HDCP 1.4
Video Bandwidth 297Mbps
Video Resolutions 480P@60Hz, 720P@60Hz, 1080P@60Hz, 1080P 3D@60Hz, 4K24/30Hz, 4K2K@50/60Hz (4:2:0)
Color Depth 8-bit, 10-bit, 12-bit
Color Space RGB/YCbCr 4:2:0, YCbCr 4:4:4, YCbCr 4:2:2
HDMI Audio Formats PCM2.0/5.1/7.1CH, Dolby 5.1, DTS5.1, Dolby-TrueHD, DTS-HD
L/R Audio Formats Analog stereo 2CH
Optical Audio Formats LPCM[2.0/2.1]CH, Dolby 5.1, Dolby True HD, Dolby DD+, DTS
5.1, DTS-ES 6, DTS-HDMA 5.1, DTS HD-HRA 5.1
ESD Protection Human-body Model：
±8kV (Air-gap discharge) , ±4kV (Contact discharge)
Connections
Input ports 4×HDMI Type A [19-pin female]
1×IR Receiver Window
Output ports 2×HDMI Type A [19-pin female]
1×L/R Audio out [3.5mm Stereo Mini-jack]
1×Optical out [S/PDIF]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 200mm(W)×80mm(D)×16mm(H)
Weight 328g
Power Supply Input: AC100~240V 50/60Hz, Output: DC5V/1A
(US/EU standards, CE/FCC/UL certified)
Power Consumption 2W (max)
Operating
Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)
