Highly productive, professional print, copy, colour scan and fax (optional) functionality
Minimum installation and operation requirements
Easy to use full colour touch panel with wizard-style navigation
Low power consumption saves energy
Long-life components provide unprecedented efficiency and reliability
HyPAS solution platform enables powerful customisations
Up to 24/12 pages A4/A3 per minute
GENERAL
PAPER HANDLING
PRINT
COPY
SCAN
Please note, a USB Printer cable is not included
General type: Colour Multifunctional for A4/A3 Format
Technology: KYOCERA ECOSYS, COLOUR Laser, HyPAS
Engine speed: Up to 24/12 pages A4/A3 per minute in colour and b/w
Resolution: 1200 x 1200 dpi (print) 600 x 600 dpi (scan/copy)
Warm-up time: Approx. 30 seconds or less
Time to first print: Approx. 7.5 seconds or less in b/w, 10.2 seconds or less in colour
Time to first copy: Approx. 8.5 seconds or less in b/w (DP) 11.0 seconds or less in colour (DP)
Dimensions (W x D x H): 590 x 590 x 753 mm (with standard Document processor)
Weight: Approx. 76 kg (with standard Document Processor)
Power consumption: Sleep-mode: 0.5W, Stand-by: 70 W, Copying/Printing: 550 W
Power source: AC 220 to 240 V, 50/60 Hz
Noise (ISO 7779): Stand-by: 34 dB(A), Copying/Printing in b/w: 52 dB(A) Copying/Printing in colour: 53 dB(A)
Safety standards: TUV/GS, CE - This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard
General memory: 1,536 MB, max. 3,072 MB
Input capacity: 100-sheet multi-purpose tray, 60-256 g/m2: A3, A4, A5, A6, B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x 432 mm) 500-sheet standard universal paper cassette, 60-256 g/m2, A3, A4, A5, B5, Ledger, Letter, Legal, Folio
Max. input capacity with options: 1,600 sheets
Duplex unit: Standard duplex unit: 60-256 g/m2
Max. output capacity: Max. 280 sheets; 250 sheets face-down (Main Tray), plus 30 sheets (standard Job Separator Tray)
Document processor: Standard reversing document processor: 50-sheet, Simplex scan 45-160 g/m2, Duplex scan 50-120 g/m2, A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm)
General paper handling: All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions
Processor: ARM Cortex-A9 Dual core1.2 GHz
Controller language: PRESCRIBE IIc
Emulations: PCL 6 (5c/XL), KPDL3 (Postscript 3 compatible), PDF Direct print, XPS Direct print and Open XPS
Fonts: 101 outline fonts (PCL 6, KPDL3, Windows Vista), 1 bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Integrated Accounting: 100 department codes
Features: Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality
Standard Interfaces: USB 2.0 (Hi-Speed), 2 x USB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT), optional Wi-Fi (IEEE 802.11b/g/n, 2 eKUIO slots, for optional internal print server or SSD hard disc and for optional fax system, Slot for optional SD Card, NFC tag
Applicable OS: All current Windows operating systems, Mac OS X Version 10.5 or higher, UNIX LINUX , as well as other operating systems on request
Max. original size: A3/Ledger
Digital copy features: Scan-once-copy-many, sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through, ID card copy, Skip blank page
Exposure modes: Auto, manual: 7 steps
Preset magnification ratios: 5 Reductions / 5 Enlargements
Zoom range: 25 - 400 % in 1% steps
Continuous copy: 1 - 999
Image adjustments: Text, photo, text + photo, Map, Printed document
File type: PDF, PDF/A, JPG, TIFF, XPS, PDF/A-1a/b, PDF/A-2a/b/u, Encrypted PDF High Compresson PDF
Scan features: Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Original recognition: Text, photo, text + photo, light text, optimised for OCR
Max. scan size: A3/Ledger
Scan functionalities: Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Network TWAIN, WIA, WSD scan
Scan resolution: 200, 300, 400, 600 dpi (256 greyscales per colour)
Scan speed: b/w: 50 ipm (300 dpi, A4), Colour: 50 ipm (300 dpi, A4)
Compatibility: ITU-T Super G3
Modem speed: Max. 33.6 kbps
Scanning speed: 2.0 second or less
Transmission speed: Max. 33.6 kbps
Scanning density: Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 256 gray scales
Max. original size: A3/Ledger
Compression method: JBIG, MMR, MR, MH
Fax features: Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
Standard interface: USB 2.0 (Hi-Speed), 2 x USB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT), optional Wi-Fi (IEEE 802.11b/g/n), 2 eKUIO slots, for optional internal print server or SSD hard disc and for optional fax system, Slot for optional SD Card, NFC tag
Warranty: 1-year warranty as standard (depending on the country). KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions
OEM: M8124CIDN
SKU: DS03514
