Invicta 24V 12Ah Lithium Battery with 4 Series Functionality

Invicta lithium batteries are available in over 20 12V, 24V and 36V sizes that consist of aluminum encased prismatic cells which have been bolted together using solid busbar connectors. These have been further reinforced with a strengthening frame to resist damaging vibrations.

Invicta lithium batteries are designed to the highest specifications to deliver a premium solution that has been proven to perform. Consisting of high-grade aluminium Lithium Iron Phosphate (LiFePO4) prismatic cells, solid busbar connectors and an integrated BMS, Invicta lithium batteries are a reliable and robust deep-cycle battery for those that need complete confidence in their system.

The integrated BMS has been engineered for the Australian market and is a robust component that provides automated protection against overcharge/discharge, temperature, short circuit, which can be monitored with Bluetooth models.

All Invicta Lithium batteries have undergone IEC62133/UL1642 certification on a cell level with selected models also achieving IEC62619 on the entire battery and BMS. This testing guarantees the performance and safety of the cells and battery in high-stress environments.

Features:

• 7-year warranty and IEC Certification
• Aluminium-encased prismatic cells
• Integrated BMS with automatic protections
• Wireless monitoring (Bluetooth range only)
• Bolted busbar intercell connectors
• Slimline and standard AGM case sizes
• Strengthening frame to resist damaging vibrations
• 2000+ genuine cycles @ 100% DoD
• Australia's widest range of 12V, 24V, 36V & 48V single battery solutions
• Independently tested in Australia
• Safe Lithium Iron Phosphate (LiFePO4) chemistry
• Automatic BMS battery protection (overcharge/discharge, temperature, short circuit and)
• Can be installed on either of their sides (not upside down)
• Less than half the weight
• Faster recharge
• More efficient use of capacity
• Can sit unused for up to 12 months
• 2 x more runtime
• Up to 10 years life

Specifications:

• Nominal Voltage: 25.6.8V
• Nominal Capacity (250C, 0.33C): 12Ah
• Terminal: M6
• Battery Length (mm): 166 ± 2mm
• Battery Width (mm): 176 ± 2mm
• Battery Height (mm): 125 ± 2mm
• Battery Weight: 3.40kg
• Max Charge Voltage: 29.2 ± 0.1V
• Standby: 27.8 ± 0.1V
• Cut off Voltage: 20V
• Max. Discharge Current: 10A
• Max. Pulse Discharge Current (3 Sec): 60A
• Max. Charge Current: 10A
• Recommended Current Charge: ≤6A
• Cycle Life (100% DoD): >2000
• Operating Temp - Charge: 0 - 500C
• Operating Temp - Discharge: -20 - 550C
• Short Circuit Release: Load Release
• Max. Series / Parallel Configuration: 4P
