24V 12A DC-DC BATTERY CHARGER WITH DUAL INPUTS

24V 12A DC-DC Battery charger with dual input (SOLAR MPPT & DC) & auto select 12V/24V input

The SBC-5936 is designed to address the issues of the wide swing of output voltages from the smart alternator, start & stop, braking regenerative EURO 5/6 vehicles in fully charging the house battery. It is suitable for use with all old alternator systems and distant house batteries.

There are 3 alternator charging modes available, Factory Preset Mode, Ignition Feed Mode, and Vibration Sensor Mode.

The built-in vibration sensor makes it possible to use the charger by just connecting to the starter battery terminal without touching the car's electrical/ electronic wiring thus avoiding any possible excuse of revoking the car's warranty.

The digital control and auto-select design of SBC-5936 make it automatically adapt to a 12V or 24V input alternator/ battery system.

This is an automatic dual-input solar & alternator-battery charger for charging 12V house battery banks of lead acid, AGM type II, and Lithium Fe Po4 batteries.

The built-in Solar charge controller is of Maximum Power Point Tracking (MPPT) technology which maximizes the PV power from your 12V solar panels to your house battery.

In the 12V alternator/ battery system, the house battery is charged by both Solar and alternator/ battery simultaneously to maximize the free solar energy.

**In the 24V alternator/ battery system the house battery is charged by Solar only when the car's alternator/ battery stops charging operation.

This is a select (battery type) and forget charger designed for fast and accurate recharge of your deep cycle house battery.

The smart multi-stage charging enables the charger to be connected permanently to your battery banks without the worry of overcharging or drying out the electrolyte.

Lead Acid Based Battery

A 3 Stage Bulk, Absorption & Float charging profile with maximum constant charging current at the Bulk Stage a Constant Voltage with decreasing charging at the Absorption Stage, and a reduced voltage Float Charge for maintenance when the battery is full.

LiFePO4 (LFP) Battery

A 2 Stage charging is especially for the LiFePO4 battery and the charging current stops at the end of the Absorption Stage.

• Dual Input from a car battery with alternator and Solar panel;
• Auto select for 12V or 24V car system;
• Design all alternators, conventional and smart alternators;
• 3 DC Charge Modes to select:
  • Vibration Sensor Mode
  • Ignition Feed Mode with Automatic or Manual Control setting.
  • Factory Preset Mode ( charging function always on )
• Suitable for Lead Acid, AGM, and LiFePO4 battery;
• Protections:
  • Self Recoverable Input Under Voltage Protection;
  • Self Recoverable Output Over Voltage Protection;
  • Self Recoverable Over Temperature Protection;
  • Self Recoverable Over Load Protection (C.C.) with constant current at decreased output voltage;
  • Self Recoverable Input Reverse Polarity Protection;
  • Output Reverse Polarity Protection by Thermal Fuse;
• Auto select for 12V or 24V car system.

• SBC5936 charger x 1pc
• Remote LED Indicator Module (with 2M cable) x1pc
• Heavy duty electrical eye connectors x 4pcs
• Plastic wire guide x 1pc
• Double-side sticker tape for the Remote Indicator Module x 1pc
• Wire for Pin Connections x 2pcs
• Spare 8 Pin Connection sticker label x 1pc
