Adventure Kings 40A 12V DC DC Charger with 6m 6AWG 50A Wiring Kit 16 mm2
• Push Button Battery Type Selection for Lithium or AGM. Quick Connect Plugs make wiring super easy
• 12/24V input ideal for 4WDs, Caravans, Boats, Trucks, Camper Trailers, Campervans & More!
• 6m of 6AWG 16mm2 twin-core wire allows for high current with low voltage drop.
• Pre-connected in-line fuse holder with 60Afuse
KINGS 25A DCDC CHARGER
•Max. Continuous Charging Current 25A
•Max. Output Power 300W
•Max. Input Current 27A
•Vehicle Input Working Voltage Range (12V) 11.8 - 18V
•Vehicle Input Working Voltage Range (24V) 23.6 - 32V
•Min. Input start-up Voltage - Vehicle 10V to recognise battery (12V to start charging)
•Solar Input Range 10 - 32V
•Vehicle Input Working Voltage Range (Ign wire NOT fitted) 12.8 - 16V
•Min. Input start-up Voltage - Vehicle (Ign Wire NOT fitted) 13.8V
•Min. Aux Battery Voltage (Lithium) 0V (Wake Function)
•Min. Aux Battery Voltage (Lead Acid) 4V
•Idle Current Draw 15mA
•Operating Temperature -20°C to 80°C (with automatic 5-stage current derating)
•Dimensions (LxWxH) 151mm x 121mm x 44mm
•Weight ~1kg
•Temperature Compensation Yes ±18mV/°C
•Temperature Sensor(s) Yes, internal + external with M8 ring terminal for accurate battery temperature
•Housing Powder coated aluminium
•LED Indicator lights Yes - for connection, charging status and errors
•Battery Chemistry Selection Yes - Lithium (LiFePO4), AGM, wet lead acid, gel, calcium
•Fuses required Yes - not supplied (50A Suggested)
•IP Rating IP66
•Built-in Protections Yes - Over Voltage, Reverse Polarity, Over-Temperature Protection
KINGS 50A WIRING KIT
•Wire Length 6m
•Wire gauge Twin Core 6 AWG (16mm2)
•Fuse Type / Rating Maxi Blade Fuse / 60A
•Fitted plug/ terminal types Pre-fitted anderson style plug and 8mm eye terminals
•Extra terminals included 8mm ring terminals x 2, Anderson style connectors x 2, Anderson style plastic housing x 2
•Spare Fuse included Yes, 2 x 60A maxi blade fuses
