2.8MM 5MP BULLET CAMERA GREY
DW MEGApix® IP cameras are NDAA compliant and deliver crystal-clear images at 5MP resolution and real-time 25fps.
The IP67-rated turret camera features a 2.8mm fixed lens and a 360° camera gimbal for absolute view adjustment.
Added intelligence includes line crossing, perimeter intrusion, video tampering detection and object classification.
All Digital Watchdog MEGApix cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.
Digital Watchdog® IP cameras, analog cameras, NVRs, DVRs, network devices and management software sold and distributed worldwide are designed and developed in U.S.A. and Korea.Manufactured in South Korea and Taiwan.
- 5MP 1/2.7” image sensor at real-time 30fps
- 2.8mm fixed lens
- True Wide Dynamic Range (WDR)
- Multiple codecs (H.265, H.264, MJPEG) with simultaneous dual-stream
- 50m range Smart IR™
- Object classification video analytics
- Line crossing video analytics
- Perimeter intrusion video analytics
- Video tampering with scene change detection video analytics
- Video tampering with video blur detection video analytics
- Video tampering with abnormal color detection video analytics
- Smart DNR™ 3D digital noise reduction
- True day/night with mechanical IR cut filter
- Programmable privacy zones
- Auto gain control (AGC)
- Backlight compensation (BLC)
- De-Fog™ extreme weather image compensation
- Auto white balance (AWB)
- Motion detection
- Audio input
- Micro SD/SDHC/SDXC class 10 card slot (card not included)
- Web server built-in
- PoE class 3 and DC12V
- ONVIF conformant, profile S
- NDAA compliant
- IP67 dust-tight and waterproof to 1m
- IK 10-rated impact-resistant
- 3 year warranty
Image sensor | 5MP 1/2.7” CMOS |
Total pixels | 2592 (H) x 1944 (V) |
Minimum scene illumination | 0.02 lux (color) |
0.0 lux (B/W) | |
S/N ratio | 50dB |
Lens | |
Focal length | 2.8mm, F1.6 (DWC-MB94Wi28T) 3.6mm, F1.6 (DWC-MB94Wi36T) |
Lens type | Fixed lens |
Field of view (FoV) | 98.5° (DWC-MB94Wi28T) 81.4° (DWC-MB94Wi36T) |
IR distance | 164ft Range |
I/O | |
Audio in / out | 1 audio input |
Audio compression | G.711A / U |
OPERATIONAL | |
Shutter mode | Auto, manual |
Shutter speed | 1/30s ~ 1/100000s |
Auto gain control | Auto |
Day / night | Auto, day (color), night (B/W), schedule |
Smart DNR™ 3D digital noise reduction | 3D DNR |
Wide dynamic range (WDR) | True WDR low, middle, high |
Wide dynamic range (WDR) dB | 120dB |
Privacy zone | 4 programmable privacy masks |
| Camera analytics | Line crossing, perimeter intrusion, video tampering detection (scene change, video blur, abnormal color detection), object classification (differentiate humans from objects) |
Alarm notifications | Notifications via e-mail or FTPserver |
| Memory slot | Micro SD / SDHC / SDXC card up to 256GB (card not Included) |
NETWORK | |
LAN | 802.3 compliance 10/100 LAN |
Video compression type | H.265. H.264, MJPEG |
Resolution | 5MP, 4MP, 2K, 3MP, 2.1MP/1080P, 720P (60Hz: 1 ~ 30fps; 50Hz: 1~25fps ) HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps; 50Hz: 1~50fps ) |
Frame rate | Up to 30fps at all resolutions |
Video bitrate | 64 Kbps ~ 8 Mbps |
Bitrate control | Multi-streaming CBR/VBR at H.264/ H.265 (controllable frame rate and bandwidth) |
Streaming capability | Dual-stream at different rates and resolutions |
IP | IPv4, IPv6 |
Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS |
Security | IP filtering, MAC filtering, authentication (ID/PW), SSL/TSL |
ONVIF conformance | Yes |
Web viewer | OS: Windows® Browser: Internet Explorer |
Video management software | DW Spectrum® IPVMS |
ENVIRONMENTAL | |
Operating temperature | -22°F ~ 140°F (-30°C ~ 60°C) |
Operating humidity | 95% RH (non-condensing) |
IP rating | IP67-rated |
| IK rating | IK10 impact-resistant |
Other certifications | CE, FCC, RoHS |
ELECTRICAL | |
Power requirement | DC 12V, PoE IEEE 802.3af Class 3. (Adapter not included) |
Power consumption | 9W |
MECHANICAL | |
Material | Metal bullet housing |
Dimensions | 8.69" x 3.16" x 2.77" (220.8 x 80.5 x70.6 mm) |
Weight | 1.52 lb (0.69 kg) |
| Warranty | 3 year warranty |
