ITEM ID:AN_GPS_A003_SMA
Ideal for GPS signal boosting in room or car.
Domestic shipment
Packages are generally dispatched within 2 days after receipt of payment and shipped via Australia Post.If you prefer delivery by Express Post, an additional cost will be applied,so please contact us via ebay messages before choosing this method.
Shipping fees include handing and packing fees as well as postage costs.Handing fees are fixed ,whereas transport fees vary according to total weight of the shipment. We advise you to group your items in one order. We cannot group two distinct orders placed seperately,and shipping fees will apply to each of them.
Warranty and Return:
All of our product has a standard 1 year return to base warranty. If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it.
Specification:
Centre Frequency 1575.42MHz±3MHz
V.S.W.R(5m) 1.5 : 1
Band Width ±5MHz
Impendence 50 ohm
Polarization Type RHCP
LNA/Filter:
LNA Gain(Without cable) 28±2 dB Typical
Noise Figure 1.5dB
DC Voltage 2.2~5V
DC current 5~15 mA
Cable RG174 (3m)
Connector SMA male
Housing Black
Working Temp-40 Degrees Celsius~+85 Degrees Celsius
Humidity 55%~75%RH
Water proof IP67
Size: D46.6*14.5mm
Mounting type: screw and 3m adhesive
Circular shape with Magnet mounting on back side.
