Timegrapher No.1000 Multifunctional Watch Tester Coaxial MTG Watch Tester AU

• The Timegrapher NO. 1000 is a precise mechanical watches test instrument, it is used for multi-testing by watch manufacturers and watch technician.
• The frequency diagram of the watch can be displayed in the LCD screen.
• According to different watches, the instrument will automatically adjust optimal signal level during testing.
• The instrument will automatically calculate the rate, amplitude, beat error, and display them by data in real time.
• For the conventional beat, the instrument can automatically respond; for the special beat, it can be manually selected.
• The sampling period can be selected by 2 seconds, 4 seconds, 6 seconds, 8 seconds, 10 seconds, 20 seconds, 30 seconds, 60 seconds, and the average of corresponding period will be regarded as the precise value of the watch.
• Six kinds of testing position can be adjusted, and the simulation sound can be played in the speaker or mute.

• Automatic: The following beat numbers are selected by automatic selection mode: 12000, 14400, 18000, 19800, 21600, 25200, 28800, 36000, 43200 (If the tested beat is not in automatic selection, the instrument will display the closest beat number, but the test result is not correct. At this time, use the manual mode to select the relative beat.)
• Manual selection: It can select out the beat number that Automatic select cannot identify and rare beat number. The following beat are selected by Manual selection mode: 3600, 6000, 7200, 7380, 7440, 7800, 9000, 9100, 10800, 11880, 12000, 12342, 12480, 12600, 13320, 13440, 13500, 14000, 14040, 14160, 14200, 14280, 14400, 14520, 14580, 14760, 14850, 15000, 15360, 15600, 16200, 16320, 16800, 17196, 17258, 17280, 17786, 17897, 18000, 18049, 18514, 19332, 19440, 19800, 20160, 20222, 20944, 21000, 21031, 21306, 21600, 25200, 28800, 32400, 36000, 43200.

The lift angle is 52° for many common movements, therefore the lift angle value of instrument for factory is set to 52°. This value is required to calculate the amplitude and must be selected according to the watch movement. The lift angle can be set to between 30° and 70°.

The measuring period selectable: 2s, 4s, 8s, 10s, 20s, 30s, 60s. Use to recalculate the average values of the test result.

• 1 x Watch Timing Machine Timegrapher
• 1 x Charger (Euro plug)
• 1 x Manual

We ensure all the items gets dispatched within 1-2 business days. More than 90% of the item gets delivered within 2-6 business days.

All of our new items comes with 1 year warranty.

If the product is faulty, it can be returned and we will help accordingly. Change of mind for some products may cost shipping fee to customer.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and loss or damage.
