Technical Specifications
- Dimensions: 1855mm x 790mm x 1050mm (L x W x H)
- Frame & Fork: 6061 Wrought Aluminum Alloy Welded Structure
- Handlebar: 7075 alloy φ28.6*22.2mm
- Battery Specifications: 73.6V33.8Ah LG Cell
- Battery Weight: 13.8kg
- Motor Rated Power: 3.0kw
- Motor Max Power: 6.0kw
- Motor Max Speed: 6800rpm
- Vehicle Power Mode: Manual push-button shift - 3x Gears
- Max Speed: Gear 1 - 25km/h, Gear 2 - 60km/h, Gear 3 - 80km/h
- Max Mileage on Flat Road: Greater than 100km @50km/h constant speed (75kg Rider)
- Max Mileage Off Road: Greater than 40km @full power (75kg Rider)
- Max Climbing Angle: 45°
- Chain Specifications: 420DX-122
- Wheelbase: 1250mm
- Front/Rear Tire Size: 70/100-19
- Front/Rear Rim Specification: 7116 alloy 1.6-19
- Braking System: 4 Piston Hydraulic φ 203 * 2.3mm disk
- Front/Rear Braking Force: ≥500N
- Seat Height: 830mm
- Min Ground Clearance: 270mm
- Shock Absorber: Left: Multi-stage spring inverted damping with adjustable precompression, 165 mm stroke, Right: Adjustable damping oil-gas composite inverted damping, 165 mm stroke
- Rear Suspension System: Lower rocker multi-link mechanism
- Rear Shock Absorber: Adjustable damping oil-gas composite inverted damping, 165 mm stroke
- Rear Reduced Piston Rod Diameter: 12mm
